Bolt - Tee Head, Chamfered | MS9432-05

• Thread Class:┬á3A
• Thread Direction:┬áRight-Hand
• Thread Length:┬á0.294 Inches Minimum And 0.334 Inches Maximum
• Fastener Length:┬á0.428 Inches Minimum And 0.448 Inches Maximum
• Head Style:┬áTee No. 6
• Head Height:┬á0.115 Inches Minimum And 0.135 Inches Maximum
• Head Length:┬á0.420 Inches Minimum And 0.440 Inches Maximum
• Width Between Flats:┬á0.310 Inches Minimum And 0.320 Inches Maximum
• Nominal Thread Diameter:┬á0.190 Inches
• Thread Quantity Per Inch:┬á32
• Minimum Yield Strength:┬á85000 Pounds Per Square Inch
• Surface Finish:┬á63.0 Microinches Bearing Surface Of Head
• Surface Finish:┬á63.0 Microinches Grip
• Surface Finish:┬á32.0 Microinches Threads
• Chamfer Angle:┬á45.0 Degrees Minimum And 47.0 Degrees Maximum
• Material:┬áIron Alloy 660 Overall
• Material Document And Classification:┬áAms 5735 Assn Std Single Material Response Overall
• Surface Treatment:┬áPassivate Overall
• Thread Series Designator:┬áUnjf
